Transporto priemonė: U 2400 TG; VIN numerio dalis: 437182

Grupė: 31 FRAME

#	Kodas	Pavadinimas
005	A 4373107501	FRAME
008	A 4373104801	FRAME
011	A 4063110087	STOP
014	A 3813120015	CROSS MEMBER
		BATTERY/APPARATUS SUPPORT
		NO.3
017	A 6523120987	GUSSET PLATE
		TOP LEFT
017	A 6523121087	GUSSET PLATE
		TOP RIGHT
020	A 6523120161	STRUT
		BOTTOM LEFT
020	A 6523120261	STRUT
		BOTTOM RIGHT
023	N 910105012007	SCREW
		GUSSET PLATE TO SIDE MEMBER
		M 12X1,5X30
026	N 913023012002	NUT
		GUSSET PLATE TO SIDE MEMBER
029	N 000961012120	SCREW
	Repalced by: N 308676012010
029	N 308676012010	HEXAGON HEAD BOLT
		TOP GUSSET PLATE TO CROSS MEMBER
		M12X1.5X40
032	N 910105012007	SCREW
		STRUT BOTTOM ON CROSS MEMBER
		M 12X1.5X30
032	N 910105012013	SCREW
		BOTTOM GUSSET PLATE TO CROSS MEMBER
038	N 000961014027	SCREW
		CROSS MEMBER TO SIDE MEMBERS
		M 14X1,5X30
038	N 000961014100	SCREW
		CROSS MEMBER TO SIDE MEMBERS
		M 14X1,5X30
041	A 3859901040	WASHER
		TOP GUSSET PLATE TO CROSS MEMBER
044	N 910113012005	NUT
		TOP GUSSET PLATE TO CROSS MEMBER
047	N 913023012002	NUT
		STRUT BOTTOM ON CROSS MEMBER
050	N 910105014013	SCREW
		CROSS MEMBER TO SIDE MEMBERS
		M 14X1,5X35
053	N 913023014003	NUT
		CROSS MEMBER TO SIDE MEMBERS
056	A 3813120017	CROSS MEMBER
		REAR SPRING FRONT BRACKET
		NO.4
059	A 6203121584	SHIM
		CROSS MEMBER TO SIDE MEMBERS
062	A 6523120361	STRUT
		CROSS MEMBER AT REAR SPRING FRONT BRACKET
065	N 910005012073	RIVET
		STRUT TO CROSS MEMBER
068	N 910105012020	SCREW
		CROSS MEMBER TO SIDE MEMBERS
		M 12X1,5X35
071	N 913023012002	NUT
		CROSS MEMBER TO SIDE MEMBERS
074	A 6523250001	REAR SPRING BRACKET
		FRONT
077	A 6523250017	HELPER SPRING BRACKET
		FRONT AND REAR
080	A 6513250041	STIFFENING
		HELPER SPRING BRACKET,FRONT
089	N 910105012007	SCREW
		REINFORCEMENT ON SIDE MEMBER
		M 12X1.5X30
089	N 910105012015	SCREW
		HELPER SPRING BRACKET AND STIFFENING TO FRAME
		M 12X1.5X45
089	N 910105012010	SCREW
	Repalced by: N 910105012047
089	N 910105012047	SCREW
		HELPER SPRING BRACKET TO SIDE MEMBER, REAR
		M 12X1,5X40
092	N 913023012002	NUT
		HELPER SPRING BRACKET AND STIFFENING TO FRAME
095	N 910105014008	SCREW
		REAR SPRING FRONT BRACKET TO SIDE MEMBER
		M 14X1,5X55
098	N 910105014009	SCREW
		REAR SPRING FRONT BRACKET TO SIDE MEMBER
		M 14X1,5X70
101	N 913023014003	NUT
		REAR SPRING FRONT BRACKET TO SIDE MEMBER
104	A 6523200643	BRACKET
		SHOCK ABSORBER,LEFT REAR
104	A 6523200743	BRACKET
		SHOCK ABSORBER,RIGHT REAR
107	N 910105014013	SCREW
		BRACKET TO SIDE MEMBER
		M 14X1,5X35
110	N 913023014003	NUT
		BRACKET TO SIDE MEMBER
113	A 6523200075	SPRING BRACKET
		(REAR SPRING BRACKET),REAR
116	A 0003220385	RUBBER MOUNTING
116	A 0003220585	RUBBER MOUNTING
119	A 6523110055	COVER
		REAR SPRING REAR BRACKET TO SIDE MEMBER
122	N 910105014011	SCREW
		REAR SPRING REAR BRACKET AND REINFORCEMENT TO SIDE MEMBER
		M 14X1,5X50
125	N 910105014019	SCREW
		REAR SPRING REAR BRACKET AND REINFORCEMENT TO SIDE MEMBER
		M 14X1,5X60
128	N 913023014003	NUT
		REAR SPRING REAR BRACKET TO SIDE MEMBER
131	A 4253120045	FLANGE
		LEFT
131	A 4253120145	FLANGE
		RIGHT
134	A 4373120635	CROSS MEMBER
		REAR CROSS MEMBER
140	N 910105016012	SCREW
		REAR CROSS MEMBER TO FRAME FLANGE
		M 16X1.5X50
140	N 910105016007	SCREW
		REAR CROSS MEMBER TO FRAME FLANGE
		M 16X1.5X45
140	N 910105016004	SCREW
		FRAME FLANGE TO SIDE MEMBER,RIGTH
		M 16X1.5X40
140	N 910105016007	SCREW
		FRAME FLANGE TO SIDE MEMBER,LEFT
		M 16X1.5X45
140	N 910105016014	SCREW
		FRAME FLANGE AND CONTROL ARM BRACKET TO SIDE MEMBER
		M 16X1,5X70
140	N 000960016274	SCREW
		M 16X1,5X105
140	N 000960016308	SCREW
		FRAME FLANGE AND CONTROL ARM BRACKET TO SIDE MEMBER
		M 16X1.5X105
155	N 910105014005	SCREW
		FRAME FLANGE TO SIDE MEMBER
		M 14X1.5X40
158	N 910105012023	SCREW
		REAR CROSS MEMBER TO FRAME FLANGE
		M 12X45
161	N 913023016001	NUT
		FRAME FLANGE AND CONTROL ARM BRACKET TO SIDE MEMBER
	Repalced by: N 000000005738
161	N 000000005738	NUT
		FRAME FLANGE AND CONTROL ARM BRACKET TO SIDE MEMBER
161	N 913023016001	NUT
		REAR CROSS MEMBER TO FRAME FLANGE
	Repalced by: N 000000005738
161	N 000000005738	NUT
		REAR CROSS MEMBER TO FRAME FLANGE
164	N 913023014004	NUT
		FRAME FLANGE TO SIDE MEMBER
164	N 913023012004	NUT
		REAR CROSS MEMBER TO FRAME FLANGE
170	A 6523120335	CROSS MEMBER
		(REAR CROSS MEMBER)
173	N 910105014005	SCREW
		REAR CROSS MEMBER TO FRAME
		M 14X1,5X40
176	N 913023014003	NUT
		REAR CROSS MEMBER TO FRAME
179	A 4253100367	BODY SUPPORT
182	A 0019880410	RUBBER MOUNTING
185	A 4253111250	BUSHING
188	A 4253170071	SCREW
	Repalced by: N 000960020188
188	N 000960020188	SCREW
	Repalced by: N 308765020011
188	N 308765020011	SCREW
		BODY SUPPORT TO FRAME
		M 20X1,5X160
191	N 910113020003	NUT
		BODY SUPPORT TO FRAME
194	A 4375200133	SUPPORT
197	A 4258917001	INTERMEDIATE BEARING
		CAB TO CHASSIS
200	A 4255240384	SHIM
		CAB TO CHASSIS
203	N 304017008016	SCREW
		CAB TO CHASSIS
		M 8X16
206	N 000000003250	WASHER
		CAB TO CHASSIS
209	A 4255250030	COUPLING MOUTH
212	A 4275250030	COUPLING MOUTH
		REAR
215	A 4259940060	LOCK
		COUPLING PIN
218	N 910105008004	SCREW
		LOCK
		M 8X20
221	N 000912012140	SCREW
		COUPLING MOUTH TO FRAME
		M 12X1.5X40
224	N 308676012010	HEXAGON HEAD BOLT
		REINFORCEMENT ANGLE TO COUPLING MOUTH
		M12X1.5X40
227	N 910113012005	NUT
230	N 910105012020	SCREW
		M 12X1.5X35
