Transporto priemonė: L 613 D; VIN numerio dalis: 313404
Grupė: 60 PLATFORM
| # | Kodas | Pavadinimas |
|---|---|---|
| 009 | A 3096001821 | BODY |
| Repalced by: A 3096002521 | ||
| 009 | A 3096002521 | BODY |
| LESS FLOOR PANELS | ||
| 4060X2000 MM | ||
| 009 | A 3096001321 | BODY |
| Repalced by: A 3096002021 | ||
| 009 | A 3096002021 | BODY |
| LESS FLOOR PANELS | ||
| 4060X2260 MM | ||
| 009 | A 3096001921 | BODY |
| Repalced by: A 3096002621 | ||
| 009 | A 3096002621 | BODY |
| LESS FLOOR PANELS | ||
| 3060X2000 MM | ||
| 009 | A 3096001521 | BODY |
| Repalced by: A 3096002221 | ||
| 009 | A 3096002221 | BODY |
| LESS FLOOR PANELS | ||
| 5060X2260 MM | ||
| 009 | A 3096001621 | BODY |
| Repalced by: A 3096002321 | ||
| 009 | A 3096002321 | BODY |
| LESS FLOOR PANELS | ||
| 4060X2260 MM | ||
| 018 | A 3096003621 | BODY |
| SUBSTRUCTURE WITH FRONT PANEL AND FLOOR BOARDS | ||
| 018 | A 3096005121 | BODY |
| SUBSTRUCTURE WITH FRONT PANEL AND FLOOR BOARDS | ||
| 018 | A 3096004821 | BODY |
| SUBSTRUCTURE WITH FRONT PANEL AND FLOOR BOARDS | ||
| 018 | A 3096003721 | BODY |
| SUBSTRUCTURE WITH FRONT PANEL AND FLOOR BOARDS | ||
| 018 | A 3096004921 | BODY |
| SUBSTRUCTURE WITH FRONT PANEL AND FLOOR BOARDS | ||
| 021 | A 3096120914 | CROSS MEMBER |
| 2016 MM | ||
| 021 | A 3096120914 | CROSS MEMBER |
| 2016 MM | ||
| 021 | A 3096122614 | CROSS MEMBER |
| 2276 MM | ||
| 021 | A 3096122614 | CROSS MEMBER |
| 2276 MM | ||
| 025 | A 3146150014 | BRACKET |
| Repalced by: A 3146100536 | ||
| 025 | A 3146100536 | BRACKET |
| 032 | A 3096120026 | INTERMEDIATE PIECE |
| 038 | N 000931008254 | SCREW |
| Repalced by: N 304014008002 | ||
| 038 | N 304014008002 | SCREW |
| BRACKET TO CROSS MEMBER | ||
| M 8X65 | ||
| 044 | N 000603008051 | SCREW |
| BRACKET TO CROSS MEMBER | ||
| M 8X55 | ||
| 050 | N 009021008205 | WASHER |
| Repalced by: N 009021008213 | ||
| 050 | N 009021008213 | WASHER |
| BRACKET TO CROSS MEMBER | ||
| Repalced by: N 000000003250 | ||
| 050 | N 000000003250 | WASHER |
| BRACKET TO CROSS MEMBER | ||
| 056 | N 912004008102 | LOCK WASHER |
| BRACKET TO CROSS MEMBER | ||
| 062 | N 304032008006 | NUT |
| BRACKET TO CROSS MEMBER | ||
| A 3096161285 | EDGING | |
| Repalced by: A 3096161485 | ||
| A 3096161485 | EDGING | |
| Repalced by: A 3096160785 | ||
| 069 | A 3096160785 | EDGING |
| LEFT | ||
| A 3096161385 | EDGING | |
| Repalced by: A 3096161585 | ||
| A 3096161585 | EDGING | |
| Repalced by: A 3096160885 | ||
| A 3096160485 | EDGING | |
| Repalced by: A 3096160985 | ||
| 079 | A 3096160985 | EDGING |
| Repalced by: A 3096161685 | ||
| 079 | A 3096161685 | EDGING |
| Repalced by: A 3096160885 | ||
| 079 | A 3096160885 | EDGING |
| REAR | ||
| 079 | A 3096160885 | EDGING |
| RIGHT | ||
| 086 | A 3096160178 | CORNER PIECE |
| FRONT LEFT | ||
| 086 | A 3096160278 | CORNER PIECE |
| FRONT RIGHT | ||
| 101 | A 3096160078 | CORNER PIECE |
| REAR | ||
| 109 | A 3096160030 | HINGE MOUNTING |
| 109 | A 3096160030 | HINGE MOUNTING |
| 117 | A 3096200002 | FRONT PANEL |
| 117 | A 3096200602 | FRONT PANEL |
| 124 | A 3096210322 | RAIL |
| LATERAL | ||
| 130 | A 3096270116 | REINFORCEMENT |
| LATERAL | ||
| 130 | A 3096270043 | RAIL |
| Repalced by: A 3096270116 | ||
| 130 | A 3096270116 | REINFORCEMENT |
| LATERAL | ||
| 138 | A 3096309403 | SIDE PANEL |
| LEFT | ||
| 138 | A 3096300652 | SIDE PANEL |
| RIGHT | ||
| 138 | A 3096309603 | SIDE PANEL |
| LEFT AND RIGHT | ||
| 149 | A 3096300082 | HINGE |
| 153 | A 3096210322 | RAIL |
| LATERAL | ||
| 156 | A 3096370014 | BRACKET |
| CHAIN ON PLATFORM SIDE PANEL | ||
| 163 | A 3526370063 | HOOK |
| FRONT LEFT AND REAR RIGHT | ||
| 163 | A 3526370163 | HOOK |
| FRONT RIGHT AND REAR LEFT | ||
| 174 | N 000933008212 | SCREW |
| Repalced by: N 304017008016 | ||
| 174 | N 304017008016 | SCREW |
| HOOK TO PLATFORM SIDE PANEL | ||
| 178 | N 912004008102 | LOCK WASHER |
| HOOK TO PLATFORM SIDE PANEL | ||
| 185 | A 3096400202 | REAR PANEL |
| Repalced by: A 3096403802 | ||
| 185 | A 3096403802 | REAR PANEL |
| 2052X407 MM | ||
| A 3096401902 | REAR PANEL | |
| Repalced by: A 3096403902 | ||
| 185 | A 3096403902 | REAR PANEL |
| 2312X407 MM | ||
| 192 | A 3096300082 | HINGE |
| 199 | A 3096270043 | RAIL |
| Repalced by: A 3096270116 | ||
| 199 | A 3096270116 | REINFORCEMENT |
| LATERAL | ||
| 205 | A 3096210322 | RAIL |
| LATERAL | ||
| 205D | A 3096270116 | REINFORCEMENT |
| 206 | A 3098500002 | FOLDING STEP |
| FOR REAR PANEL | ||
| 207 | N 000966008006 | SCREW |
| Repalced by: N 000966008031 | ||
| 207 | N 000966008031 | SCREW |
| FOLDING STEP TO REAR PANEL | ||
| 208 | N 000125008418 | WASHER |
| Repalced by: N 000125008443 | ||
| 208 | N 000125008443 | WASHER |
| FOLDING STEP TO REAR PANEL | ||
| 209 | N 912004008102 | LOCK WASHER |
| FOLDING STEP TO REAR PANEL | ||
| 210 | N 000917008007 | NUT |
| FOLDING STEP TO REAR PANEL | ||
| 211 | A 0019874740 | RUBBER BUFFER |
| FOLDING STEP | ||
| 212 | N 001434012209 | PIN |
| PLATFORM SIDE AND REAR PANELS TO SUBSTRUCTURE | ||
| 214 | N 000094003213 | COTTER PIN |
| PLATFORM SIDE AND REAR PANELS TO SUBSTRUCTURE | ||
| 215 | A 3526370011 | PLATE |
| THREADED | ||
| 217 | A 3526370013 | WASHER |
| (ECCENTRIC PLATE) PLATFORM PANEL FASTENER | ||
| 222 | A 3609902101 | SCREW |
| WASHER TO FRONT AND REAR PANELS | ||
| 223 | A 3096600075 | INSERT RAIL |
| SIDE PANEL | ||
| 223B | N 000933008147 | SCREW |
| Repalced by: N 304017008021 | ||
| 223B | N 304017008021 | SCREW |
| INSERT RAIL TO INSERT POCKET | ||
| M 8X20 | ||
| 223D | N 000603008049 | SCREW |
| INSERT RAIL TO INSERT POCKET | ||
| M 8X40 | ||
| 223H | N 000125008418 | WASHER |
| Repalced by: N 000125008443 | ||
| 223H | N 000125008443 | WASHER |
| INSERT RAIL TO INSERT POCKET | ||
| 223L | N 912004008102 | LOCK WASHER |
| INSERT RAIL TO INSERT POCKET | ||
| 223P | N 304032008006 | NUT |
| INSERT RAIL TO INSERT POCKET | ||
| 224 | A 3526370011 | PLATE |
| THREADED | ||
| 225 | A 3526370013 | WASHER |
| (ECCENTRIC PLATE) PLATFORM PANEL FASTENER | ||
| 226 | A 3609902101 | SCREW |
| WASHER TO INSERT RAIL | ||
| 228 | A 3099870040 | RUBBER BUFFER |
| PLATFORM SIDE AND REAR PANELS | ||
| A 3093110363 | CONSOLE | |
| Repalced by: A 3093111863 | ||
| 235 | A 3093111863 | CONSOLE |
| 242 | A 3093111063 | CONSOLE |
| 243 | A 3093110263 | CONSOLE |
| 244 | N 910005010020 | RIVET |
| CONSOLE TO SIDE MEMBER | ||
| 245 | N 910005010014 | RIVET |
| CONSOLE TO SIDE MEMBER | ||
| 247 | N 000960012246 | SCREW |
| Repalced by: N 000960012353 | ||
| 247 | N 000960012353 | SCREW |
| PLATFORM TO FRAME | ||
| 249 | N 000960012199 | SCREW |
| Repalced by: N 308676012018 | ||
| 249 | N 308676012018 | SCREW |
| PLATFORM TO FRAME | ||
| 251 | N 000960012153 | SCREW |
| PLATFORM TO FRAME | ||
| 253 | A 3148910111 | PLATE |
| PLATFORM TO FRAME | ||
| 255 | A 3093110784 | SHIM |
| PLATFORM TO FRAME | ||
| 257 | A 3148910113 | PLATE |
| PLATFORM TO FRAME | ||
| 260 | N 910113012002 | NUT |
| PLATFORM TO FRAME | ||
| 263 | A 0008261741 | SIDE REFLECTOR |
| Repalced by: A 0008262440 | ||
| 263 | A 0005443705 | REFLECTOR |
| Repalced by: A 0008261741 | ||
| 263 | A 0008261741 | SIDE REFLECTOR |
| Repalced by: A 0008262440 | ||
| 263 | A 0008262440 | REFLECTOR |
| AMBER | ||
| 267 | N 007981004244 | SHEET METAL SCREW |
| Repalced by: N 000000000453 | ||
| 267 | N 000000000453 | TAPPING SCREW |
| REFLECTOR TO PLATFORM | ||
| 269 | A 3098800221 | REAR FENDER |
| LEFT | ||
| 269 | A 3098800321 | REAR FENDER |
| RIGHT | ||
| 274 | N 000933008212 | SCREW |
| Repalced by: N 304017008016 | ||
| 274 | N 304017008016 | SCREW |
| FENDER TO PLATFORM FLOOR | ||
| 279 | N 000603008027 | SCREW |
| FENDER TO PLATFORM FLOOR | ||
| 283 | N 009021008205 | WASHER |
| Repalced by: N 009021008213 | ||
| 283 | N 009021008213 | WASHER |
| FENDER TO PLATFORM FLOOR | ||
| Repalced by: N 000000003250 | ||
| 283 | N 000000003250 | WASHER |
| FENDER TO PLATFORM FLOOR | ||
| 287 | N 912004008102 | LOCK WASHER |
| FENDER TO PLATFORM FLOOR | ||
| 291 | N 304032008006 | NUT |
| FENDER TO PLATFORM FLOOR | ||
| 298 | A 3098820005 | SPLASH GUARD |
| Repalced by: A 3098801422 | ||
| 298 | A 3098801422 | SPLASH GUARD |
| Repalced by: A 3098820005 | ||
| 298 | A 3098820005 | SPLASH GUARD |
| 302 | N 007985005175 | SCREW |
| MUD APRON TO FENDER | ||
| 306 | N 912004005103 | LOCK WASHER |
| MUD APRON TO FENDER | ||
| 310 | N 000934005008 | NUT |
| MUD APRON TO FENDER | ||
